CAD Design • Replacement Part
Clutch Master Cylinder Cap
Replacement component modelled in CAD from the original part, with key dimensions and mounting features recreated for functional use.
CAD • Reverse Engineering • 3D Scanning
Projects & Recent Work
A selection of CAD design, reverse engineering and 3D scanning projects completed by Vertex 3D for automotive, mechanical and functional applications.
Reverse Engineering
IS300 Master Window Switch Panel
Replacement interior component recreated in CAD to reproduce the original panel geometry, openings and mounting features for accurate vehicle fitment.
CAD Design
KX250 Fork Guard Brackets
Custom fork guard mounting brackets developed in CAD with functional clamp geometry and mounting features designed around the existing motorcycle components.
Automotive CAD Design
R32 MAF Relocation Pipe
Custom CAD intake component designed to relocate the MAF while maintaining suitable fitment, airflow path and engine bay packaging.
CAD Design • Metal Additive Manufacturing
Tommy Kaira Badge
Custom automotive badge developed in CAD and produced in titanium using metal additive manufacturing, combining detailed geometry, integrated mounting features and a premium finished result.
D Scanning • Reverse Engineering
Toyota Caldina Bonnet Scoop
3D scanned and reverse engineered to recreate the original bonnet scoop geometry and achieve accurate fitment to the existing bonnet.
3D Scanning
IS300 Engine Bay Scan
Large-area 3D scan captured to provide accurate reference geometry for custom part design, packaging checks and intake development.
